T-13C

High transparency

presenting an ultra-high-definition visual experie
High protection levelIP67

Waterproof, moisture-proof, cold-proof, dust-proof
High brightness

Up to 12000nit, experience the most realistic visu
Average power consumption

170w/㎡，Energy saving,Reduce operating costs
Super light

20.8kg/㎡
A variety of colors can be customized freely

Adapt to various architectural styles and business
Convenient installation

Support front and rear installation and maintenanc

Brightness 5000nit Normal brightness

High brightness

The application of PCB side lying and side light-emitting LED ensures that the permeability ratio of the screen is as high as 85%

It presents a dreamy visual experience without affecting the indoor daylighting

Waterproof, moisture-proof, cold-proof, dust-proof, and short-term immersion prevention

The transparency rate is as high as 85%

presenting an ultra-high-definition visual experience without affecting indoor lighting

Ensure that the screen has a permeability ratio of up to 85% do not affect indoor lighting

10mm

It can be hoisted or fixed, and there are lock con

Applicable to various structural types of shop win

Specifications

Product Type	T-13C
Body Material	Aluminum & PC Mask (appearance color can be customized)
LED	DIP346 (1R1G1B) (R≥2000mcd, G≥4000mcd, B≥900mcd)
Pixel Pitch	13.71 mm /12.8 mm
Resolution	5700 dot/m²
Panel Orientation	Horizontal \| Vertical
Standard Panel Size	1536×256mm (H)； 256×1536mm (V). Length can be customized.
Resolution/Panel	112×20 dot(H)；20×112 dot(V)；
Brightness	6000-7000 nit
Transparent Rate	6%
Weight	24.6 kg/m²
Input Voltage	AC 110 -240 V
Maximum Power Consumption	400 w/m²
Installation and Maintenance	Front or Rear
IP Grade	IP67
Grey Level	RGB 65536 (3×16bit)
Refresh Rate	≥3840 Hz
Frame Rate	≥60 Hz
Working Environment	Temperature: -30℃ to +60℃; Humidity: 10%-90%
