O series grille LED screen products
-
VT series video light products
MediaGrille®
Presenting an ultra-high-definition visual experie
Waterproof, moisture-proof, cold-proof, dust-proof
Up to 12000nit, experience the most real visual en
180w/㎡，Energy saving reduce operating costs
10.5kg/㎡
Adapt to various architectural styles and business
Support front and rear installation and maintenanc
Brightness 5000nit
Normal brightness
High brightness
The application of PCB side lying and side light-emitting LED ensures that the permeability ratio of the screen is as high as 85%
It presents a dreamy visual experience without affecting the indoor daylighting
Waterproof, moisture-proof, cold-proof, dust-proof, and short-term immersion prevention
The transparency rate is as high as 85%
Presenting an ultra-high-definition visual experience without affecting indoor lighting.
The transparency rate is as high as 85%, presenting an ultra-high-definition visual experience without affecting indoor lighting.
10mm
It can be hoisted or fixed, and there are lock con
Applicable to various structural types of shop win
| PRODUCT MODEL | O-1636E (Standard Edition) |
| LED | DIP (1R1G1B) (R≥2000mcd, G≥4000mcd, B≥900mcd) |
| MATERIAL | Aluminum Body & PC Mask (can customize the color) |
| PIXEL PITCH | 36.5 mm/16mm |
| RESOLUTION | 1710 dot/m2 |
| UNIT PERMUTATION | Vertical |
| UNIT SIZE | 256×1536mm (Vertical) (Length can be customized according to project requirement) |
| RESOLUTION/UNIT | 7×96 dot |
| BRIGHTNESS | 6000-8000 nit |
| TRANSPARENCY | 73% |
| WEIGHT | 11 kg/m2 |
| INPUT VOLTAGE | AC 110 -240 V |
| MAX.POWER CONSUMPTION | 420 w/m2 |
| INSTALLATION | Front & Back |
| PROTECTION | IP67 |
| GRAY SCALE | RGB 16384 bit (3×14bit) |
| REFRESH RATE | ≥1920 Hz |
| FRAME RATE | ≥60 Hz |
| WORKING ENVIRONMENT | Temperature: -40℃ to +60℃; Humidity: 10%-90% |
