O-2536e

High transparency

Presenting an ultra-high-definition visual experie
High protection levelIP67

Waterproof, moisture-proof, cold-proof, dust-proof
High brightness

Up to 12000nit, experience the most real visual en
Average power consumption

180w/㎡，Energy saving reduce operating costs
Super light

10.5kg/㎡
A variety of colors can be customized freely

Adapt to various architectural styles and business
Convenient installation

Support front and rear installation and maintenanc

Brightness 5000nit Normal brightness

High brightness

The application of PCB side lying and side light-emitting LED ensures that the permeability ratio of the screen is as high as 85%

It presents a dreamy visual experience without affecting the indoor daylighting

Waterproof, moisture-proof, cold-proof, dust-proof, and short-term immersion prevention

The transparency rate is as high as 85%

presenting an ultra-high-definition visual experience without affecting indoor lighting.

The transparency rate is as high as 85%, presenting an ultra-high-definition visual experience without affecting indoor lighting.

10mm

It can be hoisted or fixed, and there are lock con

Applicable to various structural types of shop win

Specifications

PRODUCT MODEL	O-2536E (Standard Edition)
MATERIAL	Aluminum Body & PC Mask (can customize the color)
LED	DIP (1R1G1B) (R≥2000mcd, G≥4000mcd, B≥900mcd)
PIXEL PITCH	25 mm /36.5 mm
RESOLUTION	1094 dot/m²
UNIT PERMUTATION	Horizontal \| Vertical
UNIT SIZE	1600×256mm (Horizontal)； 256×1600mm (Vertical) (Length can be customized according to project requirement)
RESOLUTION/UNIT	64×7 dots(Horizontal) 7×64 dots(Vertical)
BRIGHTNESS	6000-7000 nit
TRANSPARENCY	73%
WEIGHT	10 .5 kg/m²
INPUT VOLTAGE	AC 110 -240 V
MAX.POWER CONSUMPTION	350 w/m²
INSTALLATION	Front & Back
PROTECTION	IP67
GRAY SCALE	RGB 16384 bit (3×14bit)
REFRESH RATE	≥1920 Hz
FRAME RATE	≥60 Hz
WORKING ENVIRONMENT	Temperature: -40℃ to +60℃; Humidity: 10%-90%
