O series grille LED screen products
-
VT series video light products
MediaGrille®
presenting an ultra-high-definition visual experie
Up to 5500nit, experience the most real visual enj
800w/㎡，Energy saving,Reduce operating costs
14kg/㎡
Applicable to various structural types of shop win
The integrated installation with the curtain wall
Brightness 5000nit
Normal brightness
High brightness
The application of PCB side lying and side light-emitting LED ensures that the permeability ratio of the screen is as high as 85%
It presents a dreamy visual experience without affecting the indoor daylighting
The application of PCB side-sleeping and side-emitting LEDs ensures that the screen's transmittance ratio is as high as 85%
Present a dreamy visual experience without affecting indoor lighting
Ensure that the screen has a permeability ratio of up to 85% do not affect indoor lighting
10mm
It can be hoisted or fixed, and there are lock con
Applicable to various structural types of shop win
| Item | UVS Transparent ScreenUVS-10 | |
| Pixel Pitch | P3.9-7.8mm | P10.4-10.4mm |
| Pixel Density | 32768pixels/㎡ | 9216pixels/㎡ |
| Cabinet Size(WXH) | 1000*500mm | 1000*500mm |
| Cabinet Resolution | 256*64 | 96*48 |
| Transparency | ≥82％ | ≥85% |
| Brightness | 5500cd/㎡ | 5500cd/㎡ |
| Viewing Angle | H140°, V140° | H140°, V140° |
| Driving Mode | 1/11 | 1/2 |
| Material | Industrial PC | Industrial PC |
| Cabinet Weight | 7kg | 7kg |
| Grey Scale | 16bit | 16bit |
| Refresh Rate | ≥3840HZ | ≥3840HZ |
| Frame Rate | 60fps | 60fps |
| Input Voltage | 100~240 | 100~240 |
| Power Consumption(Max/Aver.) | 800/220W/㎡ | 800/220W/㎡ |
| Screen Weight | 14kg | 14kg |
| Lifespan | ≥100,000 hrs | ≥100,000 hrs |
| IP Grade | IP40 | IP40 |
| Temperature | -20℃~+60℃ | -20℃~+60℃ |
| Maintenance | rear | rear |
| Installation | hanging, fixed | hanging, fixed |
