MediaGrille®

UVF Full range of transparent screen products

  • High transparency

    presenting an ultra-high-definition visual experie

  • High brightness

    Up to 5500nit, experience the most real visual enj

  • Average power consumption

    800w/㎡，Energy saving,Reduce operating costs

  • Super light

    14kg/㎡

  • A variety of colors can be customized freely

    Applicable to various structural types of shop win

  • Convenient installation

    The integrated installation with the curtain wall

Brightness 5000nit Normal brightness

High brightness

The application of PCB side lying and side light-emitting LED ensures that the permeability ratio of the screen is as high as 85%

It presents a dreamy visual experience without affecting the indoor daylighting

High protection levelIP30

Waterproof, moisture-proof, cold-proof, dust-proof, and short-term immersion prevention

High transparency, large viewing angle

The application of PCB side-sleeping and side-emitting LEDs ensures that the screen's transmittance ratio is as high as 85%

Present a dreamy visual experience without affecting indoor lighting

A variety of colors can be customized freely

Ensure that the screen has a permeability ratio of up to   85% do not affect indoor lighting

As thin as

10mm

Easy to install

It can be hoisted or fixed, and there are lock con

Strong customization ability

Applicable to various structural types of shop win

Specifications

Item UVF Transparent Screen
Pixel Pitch P2.8-5.6mm P3.9-7.8mm P3.4-3.4mm
LED Lamp Package SMD 1415 SMD 3012 SMD 1415
Pixel Density 61952pixels/㎡ 32768pixels/㎡ 82944pixels/㎡
Cabinet Size(WXH) 1000*500mm 1000*1000mm 1000*1000mm
Cabinet Resolution 352*88dots 256*128dots 288*288dots
Transparency ≥50％ ≥82% ≥50%
Brightness 4800nits 6500nits 5000nits
Viewing Angle H140°, V140° H140°, V140° H120°, V120°
Driving Mode 1/11 1/16 1/8 1/16
Material Profile Profile Profile
Cabinet Weight 4kg 4kg 4.8kg
Grey Scale 16bit 16bit 16bit
Refresh Rate ≥3840Hz ≥3840Hz ≥3840Hz
Frame Rate 60fps 60fps 60fps
Input Voltage 100~240 100~240 100~240
Power Consumption(Max/Aver.) 11 kg/m2 9.5kg/m2 9.5kg/m2
Screen Weight 8kg 8kg 8kg
Lifespan ≥100,000 hrs 100,000 hrs ≥100,000 hrs
IP Grade IP30 IP30 IP30
Temperature -20℃~+60℃ -20℃~+60℃ -20℃~+60℃
Maintenance rear rear rear
Installation hanging, fixed hanging, fixed hanging, fixed
